MODEL NUMBER：8000-343-236

PUMP DESIGN：Positive Displacement 3 Chamber Diaphragm Pump

CHECK VALVE：(2-Way Op.) Prevents Reverse Flow & 6 Ft. Head Forward Flow

CAM：2.5 Degree

MOTOR：Permanent Magnet, P/N 11-111-00

VOLTAGE：12 VDC Nominal

PRESSURE SWITCH：Adjustable Shut-Off (Range 40-60 PSI) Factory Set @ 60 PSI, Turn On 45 PSI 5 PSI

LIQUID TEMPERATURE：170 Degrees Fahrenheit (77 Degrees Centigrade) Max.

PRIME：Self-Priming Up To 11 Ft. Vertical,Max. Inlet Pressure 30 PSI (2.1 Bar)

PORTS: 3/8"-18 NPT Female

MATERIAL OF CONSTRUCTION：PLASTICS- Polypropylene；VALVES- Viton；DIAPHRAGM- Viton；FASTENERS- Zinc Plated Steel

NET WEIGHT：4.1 Lbs (1.9 Kg)

DUTY CYCLE：Continuous (See Temperature Rise Chart)

TYPICAL APPLICATIONS：Agricultural Spraying
